296×1196 UGR<16 LED panel light

The UGR < 16 LED panel is the latest product from the low UGR LED panel category, with up-to-date glare control diffuser which can suppress high-angle light above 65 degrees to reduce visual glare and lower the UGR of LED panel.

The glare control diffuser, unlike the conventional prismatic one, have a flat surface thereby making the LED panel high grade looking.  It is perfect to be used in the hospital, dentist and gallery.

There is CRI > 90 / 95 options available.

Features

  • UGR < 16 with up-to-date glare control diffuser
  • 110 lm/W high lumen efficacy, 80+ CRI
  • TUV CB, CE and RoHS certified
  • Lifud high efficiency LED driver, flicker free
  • High efficiency LM80 SMD LEDs
  • PMMA light guide panel
  • ElecCoat™ technology provides white appearance, with superb heat dissipation performance
  • NanoGap™ technology ensures the high lumen efficacy and protection of the LEDs
  • Dimmable: DALI / 0-10V / TRIAC optional
  • 5 years warranty

* TLP-30120-36-NW-110-NU

Specification

TLP-30120-36-110-NUTLP-30120-48-105-NU
Rated Power (W) ±5%3648
Driver Output33-40VDC / 850mA33-40VDC / 1100mA
CCT (K)600040003000600040003000
LM Output (lm) ±5%396039603600504050404560
Lumen Efficacy (lm/W) ±5%11011010010510595
LED Type / QuantityJ200 / 14C16B 224pcs
LM80 Lumen Maintenance>98.8% lumen maintenance @ 6,000hrs
CRI / SDCM>80 / <6
Warranty5 years
Input Voltage*220-240VAC / 50/60 Hz
PF*≥[email protected]
THD*≤20%
Driver Efficiency*≥90%@230VAC
Life50,000 hrs
Dimmable ControlDALI / 0~10V / Traic Optional
Frame ColorWhite
IP / IK / Glow-wireIP40 / IK06 / 650℃
Temperature / HumidityWorking: -20℃~40℃ Storage: <60℃ / <75%
UGR<16
TLP-30120-38-110V-NUTLP-30120-38-110V-95-NU
Rated Power (W) ±5%38
Driver Output33-40VDC / 900mA
CCT (K)550040003000
LM Output (lm) ±5%418041803800
Lumen Efficacy (lm/W) ±5%110110100
LED Type / QuantityD200 / 14C24B 336pcs
LM80 Lumen Maintenance>98.8% lumen maintenance @ 6,000hrs
CRI>90>95
Warranty5 years
Input Voltage220-240VAC / 50/60 Hz
PF[email protected]
THD≤20%
Driver Efficiency≥90%@230VAC
Life50,000 hrs
Dimmable ControlDALI / 0~10V / Traic Optional
Frame ColorWhite
IP / IK / Glow-wireIP40 / IK06 / 650℃
Temperature / HumidityWorking: -20℃~40℃ Storage: <60℃ / <75%
UGR<16
